Dimensional drawings
C.3 Dimensional drawings of the interface modules
S7-300 Automation System Module data
C-12 Manual, 08/2006, A5E00105505-04
IM 365
The figure below shows the dimensional drawing of interface module IM 365.

 



Figure C-17 Interface module IM 365
