3.19 Digital output module SM 322; DO 64 x DC 24 V/0.3 A sourcing; (6ES7322-1BP00-0AA0)
S7-300 Module data
122 Manual, 06/2017, A5E00105505-AJ
The table below shows how channel terminals are assigned to the connector for module
SM 322; DO 64 x DC 24 V/0,3 A Sourcing.
Terminal
Function
Terminal
Function
1
O x.0
2
O x+2.0
3 O x.1 4 O x+2.1
5
O x.2
6
O x+2.2
7 O x.3 8 O x+2.3
9
O x.4
10
O x+2.4
11
O x.5
12
O x+2.5
13
O x.6
14
O x+2.6
15
O x.7
16
O x+2.7
17
1M
18
2M
19
1L+
20
2L+
21
O x+1.0
22
O x+3.0
23
O x+1.1
24
O x+3.1
25
O x+1.2
26
O x+3.2
27
O x+1.3
28
O x+3.3
29
O x+1.4
30
O x+3.4
31
O x+1.5
32
O x+3.5
33
O x+1.6
34
O x+3.6
35
O x+1.7
36
O x+3.7
37
1M
38
2M
39
1L+
40
2L+
Note
Connections x M and x L+ must be connected to a channel group.
