Siemens SIMATIC User Manual

Digital modules
3.19 Digital output module SM 322; DO 64 x DC 24 V/0.3 A sourcing; (6ES7322-1BP00-0AA0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
123
Technical specifications of SM 322, DO 64 x DC 24 V, 0,3 A Sourcing
Technical specifications
Dimensions and weight
Dimensions (W x H x D) (mm) 40 x 125 x 112 (including protective barrier, re-
quired for connections which are not in use)
Weight
ca. 260 g
Module-specific data
Supports isochronous mode
No
Number of outputs
64
Cable length
• Unshielded
• Shielded
max. 600 m
max. 1000 m
Voltages, currents, electrical potentials
Rated load voltage L+
24 V DC
Total current of outputs (per group)
For horizontal installation
• Up to 25 °C
• to 40 °C
• to 60 °C
max. 2.0 A
max. 1.6 A
max. 1.2 A
For vertical installation
• to 40 °C
• Up to 25 °C
max. 1.6 A
max. 2.0 A
Electrical isolation
• Between channels and the backplane bus
• Between channels
– In groups of
Yes
Yes
16
Isolation test voltage
500 VDC
Current consumption
• From the backplane bus
• From the user 24 V (L+) (separately for each group; no load)
Max. 100 mA
Max. 75 mA
Power loss of the module
Typ. 6.0 W
