3.24 Digital output module SM 322; DO 16 x DC 24 V/0.5 A: (6ES7322-8BH10-0AB0)
S7-300 Module data
148 Manual, 06/2017, A5E00105505-AJ
Using the module
For the use of the SM 322; DO 16 x DC24V/0.5A, the following hardware and software
requirements must be fulfilled:
● For the central use in S7-300, the module can be used with all available CPUs.
● For the decentral use in ET 200M, the module can be used with the following IM 153-
modules and compatible successor modules:
– IM 153-2; as of 6ES7153-2BA02-0XB0, (PROFIBUS).
– IM 153-2; as of 6ES7153-2BA82-0XB0; (PROFIBUS, OUTDOOR).
– IM 153-4; as of 6ES7153-4BA0x-0XB0; (PROFINET).
● Requirement: STEP 7 V5.5 (HSP0217) or higher.
● A GSD file or a GSDML file must be used if the module is part of a distributed and
controlled by a master produced by a third-party manufacturer. The corresponding file for
the selected IM 153 is available for download from the Internet
(
http://www.siemens.com/automation/service&support
).
● Module diagnosis and identification data (I&M) are available through STEP 7 and with
SIMATIC PDM as of V6.0 + SP5 (HSP0217) or SIMATIC PDM V7.0 or higher and EDD
for ET 200M "DP_IOSystem_Siemens_ET200M_Module.Device" as of V1.1.12.
Compatible use of the module 6ES7322-8BH0x-0AB0
You can repalce the digital output module 6ES7322-8BH0x-0AB0 without changing your
settings through a digital output module 6ES7322-8B
10-0AB0.
In this case, the module does not offer discrepancy failure monitoring.
If a STEP 7 version before STEP 7 V5.1 SP3 is used, the replacement value behavior will
only be entered through the parameter dialog from HW config and transferred to the module
during system startup.
In this case, all other settings must be transferred through SIMATIC PDM or in the user
program through datasets to the module.
These settings are not saved retentively on the digital output module 6ES7322-8BH
10-0AB0
and are reset after restarting the module.
Note
A setting through SIMATIC PDM is only possible with the use of a 6ES7322
-8BH
10
-
0AB0 as
a replacement for a 6ES7322
-8BH
0x
-0AB0 as long as the device label
(6ES73
22-8BH
0x
-0AB0) in SIMATIC PDM was not updated with the actual device label
through Device
-> Load in PC/PG.
Redundant use of the module
A redundant use of the module is only permissible if the 6ES7322-8BH10-0AB0 is used and
configured for both modules. No short-circuit monitoring occurs according to L+ in redundant
use.
