Digital modules
3.24 Digital output module SM 322; DO 16 x DC 24 V/0.5 A: (6ES7322-8BH10-0AB0)
S7-300 Module data
150 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Table 3- 22 Technical specifications SM 322; DO 16 x DC 24V/0.5A
Technical specifications
Dimensions and Weight
Dimensions W x H x D (mm) 40 x 125 x 120
Weight
approx. 300 g
Module-specific data
Supports isochronous mode
No
Number of outputs
16
Cable length
• Unshielded
Max. 600 m
• Shielded
Max. 1000 m
Voltages, Currents, Potentials
Nominal load voltage L+
24 V DC
• Reverse polarity protection
Yes
Total current of outputs (per group)
• Horizontal mounting position to 60 °C
Max. 2 A
• Vertical mounting position to 40 °C
Max. 2 A
Electrical isolation
• Between channels and the backplane bus
Yes
• between channels
in groups of
yes
4
Insolation tested with
DC 500 V
Power consumption
• From the backplane bus
Max. 100 mA
• From load voltage L+ (without load)
Max. 100 mA
Power dissipation of the module
Typically 6 W
Status, Interrupts, Diagnostics
Status LEDs
Green LED per channel
Interrupts
• Diagnostic interrupt
Programmable
Diagnostic functions
Programmable
• Group error display
Red LED (SF)
• Channel error display
red LED, per channel
• Diagnostic information readable
supported
