Digital modules
3.32 Digital output module SM 322; DO 8 x AC 120/230 V/2 A ISOL (6ES7322-5FF00-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
193
SM 322; DO 8 x AC 120/230 V/2 A ISOL - Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D 40 x 125 x 117
Weight
approx. 275 g
Module-specific data
Supports parameter reassignment in RUN
Yes
Reaction of non-programmed outputs
Return the output value which was valid before the
parameterization
Supports isochronous mode
No
Number of outputs
8
Cable length
unshielded
shielded
max. 600 m
max. 1000 m
Voltages, currents, electrical potentials
Rated load voltage L1
120/230 V AC
Total current of outputs (module)
Horizontal mounting position
to 40 °C
to 60 °C
max. 8 A
max. 4 A
vertical mounting position
to 40 °C
max. 4 A
Electrical isolation
between channels and the backplane bus
yes
between channels
in groups of
yes
1
Maximum potential difference
between M
internal
and outputs
230 V AC
between outputs
500 V AC
Isolation test voltage
between M
internal
and outputs
1500 V AC
between outputs of different groups
2000 V AC
Current consumption
from the backplane bus
from load voltage L1 (no-load)
max. 100 mA
max. 2 mA
Power loss of the module
typ. 8.6 W
