Siemens SIMATIC User Manual

Digital modules
3.36 Relay output module SM 322; DO 8 x Rel. AC 230 V/5 A; (6ES7322-1HF10-0AA0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
219
Technical specifications
Voltages, currents, electrical potentials
Rated power supply L+ to the relays 24 V DC
Total current of outputs (per group)
• horizontal mounting position
to 30 °C
to 60 °C
• vertical mounting position
to 40 °C
max. 8 A
max. 5 A
max. 5 A
Electrical isolation
• between channels and the backplane bus
yes
• between channels
in groups of
yes
1
Maximum potential difference
• Between M
internal
and the power supply to relays and outputs
250 V AC
• Between outputs of different groups
500 V AC
Isolation test voltage
• between M
internal
and the power supply to relays
500 V DC
• between M
internal
and the power supply to relays and outputs
1500 V AC
• between outputs of different groups
2000 V AC
Current consumption
• from the backplane bus
• from power supply L+
max. 40 mA
max. 125 mA
Power loss of the module
typ. 3.2 W
Status, interrupts, diagnostics
Status display
Interrupt
Diagnostic functions
green LED per channel
none
none
