Analog modules

6.5 Analog input module SM 331; AI 8 x 14 Bit High Speed; isochrone; (6ES7331-7HF0x-0AB0)

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

331

Wiring: 2-wire and 4-wire transducers for current measurement

Figure 6-8 Block diagram and wiring diagram

Measuring range module settings

Measuring range

Measuring range module setting

2-wire transducer

4 mA to 20mA

4-wire transducer ± 20mA

0 mA to 20mA

4 mA to 20mA
