Analog modules
6.11 Analog input module SM 331, AI 6 x TC isolated (6ES7331-7PE10-0AB0)
S7-300 Module data
418 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Interference frequency suppression, error limits
Interference frequency suppression at f = n x (f1 ± 1%), (f1 = interference frequency) n = 1.2, etc.
• Common mode interference (CMV < 250 VAC)
• Series-mode interference (peak interference value <
rated input range)
> 130 dB
(3)
> 90 dB
Crosstalk between inputs > 130 dB
(3)
Operational limit (across entire temperature range, relative to measurement range end value in the selected input range, 0-
60 °C).
Note: This limit does not cover the temperature-error comparison points.
Voltage input
• ± 25 mV
• ± 50 mV
• ± 80 mV
• ± 250 mV
• ± 500 mV
• ± 1 V
± 0.12%
± 0.08%
± 0.06%
± 0.05%
± 0.05%
± 0.05%
Thermocouple
(4) (5)
Type T
-200 °C to
+400 °C
± 0.6 °C
-230 °C to
-200 °C
± 1.6 °C
Type U
-150 °C to
+600 °C
± 0.9 °C
-200 °C to
-150 °C
± 1.2 °C
Type E
-200 °C to
+1000 °C
± 0.5 °C
-230 °C to
-200 °C
± 1.3 °C
Type J
-150 °C to
+1200 °C
± 0.5 °C
-210 °C to
-150 °C
± 1.2 °C
Type L
-150 °C to
+900 °C
± 0.9 °C
-200 °C to
-150 °C
± 1.7 °C
Type K
-150 °C to
+1372 °C
± 0.8 °C
-220 °C to
-150 °C
± 1.6 °C
Type N
-150 °C to
+1300 °C
± 1.1 °C
-220 °C to
-150 °C
± 1.9 °C
Type R
+100 °C to
+1769 °C
± 1.2 °C
-50 °C to +100 °C ± 2.2 °C
Type S
+100 °C to
+1769 °C
± 1.2 °C
-50 °C to +100 °C ± 1.9 °C
Type B
(5)
+700 °C to
+1820 °C
± 1.7 °C
+500 °C to
+700 °C
± 1.9 °C
+200 °C to
+500 °C
± 4.4 °C
Type C
+100 °C to
+2315 °C
± 2.3 °C
0 °C
+100 °C
± 2.5 °C
Type TxK/XK(L)
-150 °C
+800 °C
± 1.0 °C
-200 °C
-150 °C
± 1.5 °C
