6.11 Analog input module SM 331, AI 6 x TC isolated (6ES7331-7PE10-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
419
Technical specifications
Basic error limit (operational limit at 25 °C, relative to the measurement range end value in the selected input range)
Voltage input
• ± 25 mV
• ± 50 mV
• ± 80 mV
• ± 250 mV
• ± 500 mV
• ± 1 V
± 0.04%
± 0.03%
± 0.03%
± 0.02%
± 0.02%
± 0.02%
Thermocouple
(5)
Type T
-150 °C to
+400 °C
± 0.4 °C
-230 °C to
-150 °C
± 1.0 °C
Type U
-150 °C to
+600 °C
± 0.4 °C
-200 °C to
-150 °C
± 1.0 °C
Type E
-100 °C to
+1000 °C
± 0.2 °C
-230 °C to
-100 °C
± 1.0 °C
Type J
-150 °C to
+1200 °C
± 0.2 °C
-210 °C to
-150 °C
± 0.5 °C
Type L
-50 °C to
+900 °C
± 0.4 °C
-200 °C to
-50 °C
± 1.0 °C
Type K
-100 °C to
+1372 °C
± 0.3 °C
-220 °C to
-100 °C
± 1.0 °C
Type N
-150 °C to
+1300 °C
± 0.5 °C
-220 °C to
-150 °C
± 1.2 °C
Type R
+200 °C to
+1769 °C
± 0.8 °C
-50 °C to
+200 °C
± 1.5 °C
Type S
+100 °C to
+1769 °C
± 0.8 °C
-50 °C to +100 °C ± 1.5 °C
Type B
(5)
+700 °C to
+1820 °C
± 1.0 °C
+500 °C to
+700 °C
± 1.3 °C
+200 °C to
+500 °C
± 3.0 °C
Type C
+100 °C to
+2315 °C
± 0.5 °C
0 °C to
+100 °C
± 1.0 °C
Type TxK/XK(L)
-150 °C to
+800 °C
± 0.5 °C
-200 °C to
-150 °C
± 1.0 °C
The accuracy of the temperature measurement with internal
compensation (terminal temperature)
is derived from:
(4) (6)
• Error for the analog input of the type of thermocou-
ple used
• Measuring accuracy for the temperature of the
internal reference junction ± 1.5 K
