6.13 Analog output module SM 332; AO 4 x 16 bit; isochrone; (6ES7332-7ND02-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
453
Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight
ca. 220 g
Module-specific data
Supports parameter reassignment in RUN
• Reaction of non-programmed outputs
yes
return the output value which was valid before the
parameterization
Supports isochronous mode
yes
Number of outputs
4
Cable length
• shielded
max. 200 m
Voltages, currents and potentials
Rated load voltage L+
• Reverse polarity protection
24 V DC
yes
Electrical isolation
• between channels and the backplane bus
• between channels and electronics power supply
• between channels
yes
yes
yes
Maximum potential difference
• between outputs (ECM)
• between M
ANA
and M
internal
(V
ISO
)
200 V DC / 120 V AC
200 V DC / 120 V AC
Isolation test voltage
1500 V DC
Current consumption
• from the backplane bus
• from load voltage L+ (no-load)
max. 120 mA
max. 290 mA
Power loss of the module
typ. 3 W
Generation of analog values
Resolution (including sign)
• ± 10 V
• 0 V to 10 V
• 1 V to 5 V
• ± 20 mA
• 0 mA to 20 mA
• 4 mA to 20 mA
16 bits
15 bits
14 bits
16 bits
15 bits
15 bits
Conversion time (per channel)
• in standard mode
• in isochronous mode
<200 μs
640 µs
