Analog modules
6.13 Analog output module SM 332; AO 4 x 16 bit; isochrone; (6ES7332-7ND02-0AB0)
S7-300 Module data
454 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Basic execution time of the module (independent of the number of
enabled channels)
• in standard mode
• in isochronous mode
<800 μs
750 µs
Transient recovery time
• with resistive load
• with capacitive load
• with inductive load
0.2 ms
3.3 ms
0.5 ms (1 mH) / 3.3 ms (10 mH)
Interference suppression, error limits
Crosstalk between outputs > 100 dB
Operational limit (across entire temperature range, relative to measurement range end value in the selected output range)
• Voltage output
• Current output
±0.12%
±0.18%
Basic error limit (operational limit at 25 °C, relative to the measurement range end value in the selected output range)
• Voltage output
± 10 V
0 V to 10 V
1 V to 5 V
±0.02%
±0.02%
±0.04%
• Current output
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
±0.02%
±0.02%
±0.04%
Temperature error (relative to output range)
• Voltage output
• Current output
± 0.0025%/K
± 0.004%/K
Linearity error (relative to output range)
±0.004%
Repeat accuracy (in transient state at 25°, relative to output range)
±0.002 %
Output ripple; range 0 Hz to 50 kHz (relative to output range)
±0.05 %
Status, interrupts, diagnostics
Interrupts
• Diagnostic interrupt
programmable
Diagnostic functions
• Group error display
• Reading diagnostic information
programmable
red LED (SF)
supported
Set substitute values
yes, programmable
