6.13 Analog output module SM 332; AO 4 x 16 bit; isochrone; (6ES7332-7ND02-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
455
Technical specifications
Actuator selection data
Output ranges (rated values)
• Voltage
± 10 V
0 V to 10 V
1 V to 5 V
• Current
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
Load impedance (in the rated range of the output)
• For voltage outputs
– Capacitive load
Min. 1 kΩ
Max. 1 µF
• For current outputs
– inductive load
max. 500 Ω
max. 1 mH
Voltage output
• Short-circuit protection
• Short-circuit current
yes
max. 40 mA
Current output
• noload voltage
max. 18 V
Destruction limit against external voltages/currents
• Voltage at outputs to M
ANA
• Current
max. 15 V, continuous
75 V for the duration of max. 1 s
(duty factor 1:20) 20)
max. 50 mA d.c.
Wiring of the actuators
• for voltage output
– 4-wire connection (measuring lead)
• for current output
– 2-wire connection
using a 20-pin front connector
supported
supported
Configuration in RUN
Special considerations must be given if you use the Configuration in RUN function.
SF LED is lit:
Status before re-configuration diagnostics on, SF LEDs lit among others (on CPU, IM or
module), although diagnostics are no longer pending and the module is operating correctly.
Solution:
● Only change the configuration when no diagnostics are pending for the module or
● Pulling and plugging the module.
