6.16 Analog IO module SM 334; AI 4/AO 2 x 8/8 Bit; (6ES7334-0CE01-0AA0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
479
Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight
ca. 285 g
Module-specific data
Supports isochronous mode
no
Number of inputs
4
Number of outputs
2
Cable length
• shielded
max. 200 m
Voltages, currents, electrical potentials
Rated supply voltage of the rated electronics and load voltage L+
24 VDC
Electrical isolation
• between channels and the backplane bus
• between channels and electronics power supply
no
yes
between channels
no
Maximum potential difference
• between inputs and M
ANA
(CMV)
• between inputs (CMV)
1 VDC
1 VDC
Isolation test voltage
500 VDC
Current consumption
• from the backplane bus
• from supply and load voltage L+ (no load)
max. 55 mA
max. 110 mA
Power loss of the module
typ. 3 W
Generation of analog input values
Measuring principle
• Resolution (including overshoot range)
Actual value conversion
8 bits
Integration/conversion time (per channel)
• programmable
• Integration time in µs
no
<500
Basic execution time of inputs
max. 5 ms
Time constant of the input filter 0.8 ms
