6.16 Analog IO module SM 334; AI 4/AO 2 x 8/8 Bit; (6ES7334-0CE01-0AA0)
S7-300 Module data
480 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Generation of analog output values
• Resolution (including overshoot range)
8 bits
Conversion time (per channel)
• programmable
• Conversion time in µs
no
<500
Basic execution time of outputs max. 5 ms
Transient recovery time
• with resistive load
• with capacitive load
• with inductive load
0.3 ms
3.0 ms
0.3 ms
Interference frequency suppression, error limits for inputs
Interference frequency suppression at F = n (f1 ± 1 %) (f1 = interference frequency)
• Common mode interference (V
pp
< 1 V)
> 60 dB
Crosstalk between outputs
> 50 dB
Operational limit (across entire temperature range, relative to measurement range end value in the selected input range)
• Voltage input
• Current input
± 0,9 %
± 0,8 %
Basic error limit (operational limit at 25 °C, relative to measurement range end value of the selected input range)
• Voltage input
• Current input
± 0,7 %
± 0,6 %
Temperature error (relative to input range)
± 0.005 %/K
Linearity error (relative to input range)
± 0,05 %
Repeat accuracy (in transient state at 25 °C, relative to input range)
± 0,05 %
Output ripple; range 0 Hz to 50 kHz (relative to output range)
± 0,05 %
Interference frequency suppression, error limits of outputs
Crosstalk between outputs
> 40 dB
Operational limit (across entire temperature range, relative to measurement range end value in the selected output range)
• Voltage output
• Current output
± 0,6 %
± 1,0 %
Basic error limit (operational limit at 25 °C, relative to the measurement range end value in the selected output range)
• Voltage output
• Current output
± 0,5 %
± 0,5 %
Temperature error (relative to output range)
± 0.02 %/K
Linearity error (relative to output range)
± 0,05 %
Repeat accuracy (in transient state at 25 °C, relative to output range)
± 0,05 %
Output ripple (bandwidth relative to output range) ± 0,05 %
Status, interrupts, diagnostics
Interrupts
none
Diagnostic functions
none
