Parameter sets of signal modules
A.6 Parameters of analog input modules
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
537
Measurement type
Code
Measuring range
Code
4-wire transducer 2#0010 ±3.2 mA
±10 mA
0 to 20 mA
4 to 20 mA
±20 mA
±5 mA
2#0000
2#0001
2#0010
2#0011
2#0100
2#0101
2-wire transducer
2#0011
4 to 20 mA
2#0011
Resistance (4-wire con-
nection)
2#0100 150 Ω
300 Ω
600 Ω
10 k Ω
2#0010
2#0100
2#0110
2#1001
Resistance 4-wire connec-
tion; 100 Ω compensation
2#0110 52 Ω to 148 Ω
250 Ω
400 Ω
700 Ω
2#0001
2#0011
2#0101
2#0111
Thermal resistance +
linearization 4-wire con-
nection
2#1000 Pt 100 Klima
Ni 100 Klima
Pt 100 Standard range
Pt 200 Standard range
Pt 500 Standard range
Pt 1000 Standard range
Ni 1000 standard range
Pt 200 Klima
Pt 500 Klima
Pt 1000 Klima
Ni 1000 Klima
Ni 100 standard range
2#0000
2#0001
2#0010
2#0011
2#0100
2#0101
2#0110
2#0111
2#1000
2#1001
2#1001
2#1011
Thermocouples with inter-
nal comparator
2#1010 Type B [PtRh - PtRh]
Type N [NiCrSi-NiSi]
Type E [NiCr-CuNi]
Type R [PtRh -Pt]
Type S [PtRh -Pt]
Type J [Fe - CuNi IEC]
Type L [Fe-CuNi]
Type T [Cu - CuNi]
Type K [NiCr-Ni]
Type U [Cu -Cu Ni]
2#0000
2#0001
2#0010
2#0011
2#0100
2#0101
2#0110
2#0111
2#1000
2#1001
Thermocouples with ex-
ternal comparison
2#1011
Thermocouples + lineari-
zation internal comparison
2#1101
Thermocouples + lineari-
zation external compari-
son
2#1110
See also
Analog modules (Page 300)
