Digital modules
3.1 Module overview
S7-300 Module data
54 Manual, 06/2017, A5E00105505-AJ
Table 3- 6 Digital output modules (continued)
Properties
Module
SM 322; DO 8 x
DC24V/0,5A with
diagnostics interrupt
(-8BF00-)
SM 322; DO 8 x
DC48-125V/1,5A
(-1CF00-)
SM 322; DO 8 x
AC120/230 V/2A
(-1FF01-)
SM 322;DO 8 x
AC120/230 V/ 2A
ISOL
(-5FF00-)
Number of outputs 8 DO; isolated in
groups of 8
8 DO; electrically iso-
lated in groups of 4,
with reverse polarity
protection
8 DO; isolated in
groups of 4
8 DO; isolated in
groups of 1
Output current
0.5 A
1.5 A
2 A
2 A
Rated load voltage
24 V DC
48 to 125 V DC
120/230 V AC
120/230 V AC
Suitable for... solenoid valves, DC contactors and signal
lamps
AC solenoid valves, contactors, motor starters,
FHP motors and signal lamps.
Supports isochronous
mode
No No No No
Programmable
diagnostics
Yes No no yes
Diagnostic interrupt
Yes
No
no
yes
Substitute value output
Yes
No
no
yes
Special features Redundant load con-
trol is supported
- Fuse blown display.
Replaceable fuse for
each group
-
* This module is described in the ET 200M Signal Modules for Process Automation manual.
You can find the manual on the Internet
(
http://support.automation.siemens.com/WW/view/en/7215812
).
