Parameter sets of signal modules

A.14 Parameters of analog IO modules

S7-300 Module data

582 Manual, 06/2017, A5E00105505-AJ

Measuring methods and ranges

The table below lists all measuring methods/ranges of analog IO modules, including their

codes. Enter these codes at bytes 2 to 5 in data record 1 (refer to the previous figure.)

Table A- 35 Measuring range codes of analog IO modules

Measuring method

Code

Measuring range

Code

disabled

2#0000

disabled

2#0000

Voltage 2#0001 0 V to 10 V 2#1000

Resistance (4-wire connection)

2#0100

10 kΩ

2#1001

Thermal resistance + linearization 4-wire connection

2#1000

Pt 100 Klima

2#0000

Output types and output ranges

The table below lists all output types/ranges of analog IO modules, including their codes.

Enter these codes at bytes 6 and 7 of data record 1 (refer to the previous figure.)

Table A- 36 Output range codes of analog IO modules

Output type

Code

Output range

Code

disabled

2#0000

disabled

2#0000

Voltage 2#0001 0 V to 10 V 2#1000

Product type designation	SIMATIC
CPU	Varies by model
Memory	Varies by model
Input/Output	Varies by model
Communication	Varies by model
Programming Language	STEP 7
Operating Temperature	0°C to 60°C (varies by model)
Protection Class	IP20
Category	Programmable Logic Controller (PLC)

Siemens SIMATIC User Manual
