Siemens SIMOCODE pro PCS 7

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
103
4.3.4
Motor current
The motor current is transferred via the input parameter PZDIn23 as an unsigned 2-byte
value. SIMOCODE pro always transfers the current here as a percentage of the set current
in a range from 0 to 1020%.
The
MotCurr parameter calculates this as a percentage.
The
MotCurrE parameter calculates the motor current actually drawn in amps based on the
set current for the motor configured in SIMOCODE.
Note
The motor current is only calculated if the current measuring module is connected to the
SIMOCODE
pro device and configured.
4.3.5
Device functions
Parameter DevFunc
The DevFunc parameter provides information about the parameterization of SIMOCODE pro
and the configuration of further modules by reading the DS105. The data are relevant for:
● Device class
● Control function
● Status thermistor
● Status analog module
● Status temperature
● Status ground fault module
● Status voltage module
● Current measuring module
● Analog module
● Digital module
The structure of the
DevFunc parameter can be found in the UDT "OPERATION".
