1.8 Parameterization softwares

SIMOCODE pro PCS 7 Library V9.0

34 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001

1.8.2.1

Parameter settings

The following list shows the settings for the parameters in SIMOCODE ES.

Table 1- 3 Parameter settings in SIMOCODE ES

Control function

Template

APL block

Parameters in SIMOCODE ES

Non-

main-

tained

command

Saving

change-

over

command

Feedback

time

Execution

time

Interlock-

ing time

Change-

over

pause

Overload relay

OvlRly

MMOprtn

–

Direct starter Direct MotL Default –

①

– –

Reversing starter Reverse MotRevL Default Default

①

–

Circuit breaker MCCB MotL Default –

①

– –

Star-delta starter StarDel MotL Default –

①

– –

Star-delta revers-

ing starter

RevStarDel MotRevL Default Default

①

②

–

Dahlander Dahland MotSpdL Default Default

①

–

③

Dahlander revers-

ing starter

DevDahl MMRevDhl Default Default

① ② ③

Pole-changing

starter

PoleChng MotSpdL Default Default

①

–

③

Pole-changing

reversing starter

RevPoleCh MMRevDhl Default Default

① ② ③

Solenoid valve SolValve VlvL Default – –

①

– –

Positioner 1 Positner VlvMotL Default –

①

②

–

Positioner 2 Positner VlvMotL Default Default

①

②

–

Positioner 3 Positner VlvMotL Default –

①

②

–

Positioner 4 Positner VlvMotL Default –

①

②

–

Positioner 5 Positner VlvMotL Default –

①

②

–

Soft starter SoftStr MotL Default –

①

– –

Soft reversing

starter

RevSoftStr MotRevL Default Default

①

②

–

①

< Dynamic monitoring time, MonTiDynamic ≥ MonTiStatic, MonTiDyStop

②

< Pause time, IdleTime

③

< Change-over time, SwOverTi

– not applicable
