A.6 Block parameter MMLog
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
267
A.6
Block parameter MMLog
Input parameters
Table A- 19 Input parameter MMLog
Parameter
Data format
Default setting
Meaning
Mode
DWORD
16#00
OMODE information from MOD_SWT block
DAddr INT 0 Diagnostic address of SIMOCODE module
LAddr
INT
0
Logical address of the SIMOCODE module
Slv_Typ BOOL FALSE 0 = PROFIBUS
1 = PROFINET
RackF STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#FF
1 = Rack failure information from MMDiag block
ModF STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#FF
1 = Module failure information from MMDiag block
DevFunc
DWORD
16#00
SIMOCODE Device Functions
PZDIn01
WORD
16#00
Process value DP 0.0-1.7
RdDataLi STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#FF
Input 0->1: Read data record via interconnection or SFC
RdDataOp
BOOL
FALSE
1 = Read data from datasets
SampleTime
REAL
0.1
Sampling Time [s]
OnOp BOOL FALSE 1 = ON mode:
ON mode by operator
OosOp BOOL FALSE 1 = Oos Mode:
Oos Mode by Operator
OosLi STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#FF
1 = Out of Service mode:
Out of Service mode via field signal
RunUpCyc
INT
3
Number of cycles for which all messages are suppressed
MsgEvId1
DWORD
16#00
Message Event ID block 1
MsgEvId2
DWORD
16#00
Message ID message block 2
RdEn
BOOL
TRUE
1 = Enable read data record
BatchEn BOOL FALSE Enable Remote Operation of Controller by Batch Recipe
BatchID
DWORD
16#00
Current Batch ID (number)
BatchName STRING Current batch name
