Description of the blocks
4.1 Functions for all blocks
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
75
4.1.4
Quality code
The process values of the function blocks are generated and transferred along with a signal
status as a structured variable. This contains a statement about the signal quality. The
function blocks determine the appropriate signal status for their process outputs depending
on the signal status of the process inputs. The signal status is formed from the input
parameters according to the priority table below (highest priority is 0). This group status is
displayed in the status bar of the faceplate and of the block icon. The signal status is
displayed for each individual parameter in the faceplate next to the process values.
Table 4- 3 Quality Code
Quality
Code
Priority
1
Occurs when...
Meaning
MMDiag
MMMeas
MMStat
MMLog
MMRevDhl
MMOprtn
16#80
6
No error
Good
X
X
–
X
X
16#60 –
SimOn
Simulated
value
– – – X –
16#00
0
• RackF_Act
•
ModF_Act
•
BusFlt
Bad, device-
specific, value
not valid
X
X
1 X X X
16#28 1
• Subnet error
Rack1Err or
Rack2Err
• OB not load-
ed.
Bad, device-
specific
X – – – –
16#28 2 From preceding
blocks
Bad, process-
specific
– X – X X
16#68 3 General warning Uncertain,
device-specific
X – – X X
16#A4 – Maintenance
demand
– – – X –
16#FF
–
Default setting
–
–
X
–
–
–
1
highest priority is 0
"X"= The Quality Code occurs in this block, "–" = The quality code does not occur in this block.
