Siemens SIMOCODE pro PCS 7

Description of the blocks
4.1 Functions for all blocks
SIMOCODE pro PCS 7 Library V9.0
76 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Icons
The icons for the Quality Code are displayed in the block icon and in the overview window of
the faceplates.
Table 4- 4 Icons for Quality Code display
Quality Code
Symbol
Meaning
16#80 Good
16#60 Local function check / simulation
16#00
1
Bad, device-specific, value not valid
16#28
1
Bad, process-specific
16#68 Uncertain, device-specific
16#A4 Maintenance demand
1
Active Quality Codes for the Trip, Intlock, Permit, and Protect parameters in the interlock
status.
Reference
You can obtain further information on the Quality Code display, in the PCS 7 libraries APL
Styleguide programming manual in the Internet
(https://support.industry.siemens.com/cs/document/59062870
).
