Siemens SIMOCODE pro PCS 7

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
113
4.3.16
System text libraries for warning and trip
System text libraries are created if MMOprtn blocks are inserted into the CFC chart. They
are assigned the numbers of the warnings and trips.
Numbers for warnings
Table 4- 23 Numbers for warnings
WrngNo
Text
1
Pre-warning overloaded
2 Unbalance
3
Overload
4 Overload and loss of phase
5
Internal earth fault
6
External earth fault
7
Thermistor trip level
8
Thermistor short circuit
9
Thermistor open circuit
10
TM1 level T >
11
TM1 sensor fault
12
TM1 out of range
13
Level I >
14
Level I <
15
Level P >
16
Level P <
17
Level Cos-Phi <
18
Level U <
19
AM1 level 0/4-20mA >
20
AM1 level 0/4-20mA <
21
Stalled rotor
22
No start possible
23 Number of starts >
24
Just one start possible
25 Motor operating hours >
26
Motor stop time >
27
External fault 1
28
External fault 2
29
External fault 3
30
External fault 4
31
External fault 5
32
External fault 6
33
AM1 open circuit
34
DM-F safety-oriented tripping
