Parameter
A.5 Block parameter MMStat
SIMOCODE pro PCS 7 Library V9.0
260 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
TM2Temp2 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
TM2 Temperature 2 in Celsius
TM2Temp3 STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
TM2 Temperature 3 in Celsius
A.5
Block parameter MMStat
Input parameters
Table A- 16 Input parameter MMStat
Block parameters
Data format
Default setting
Meaning
Mode DWORD 16#8000FFFF
OMODE
information from the MOD_SWT block
DAddr
INT
0
Diagnostic address of SIMOCODE module
LAddr INT 0 Logical address of the SIMOCODE module
RackF STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Rack Failure information from MMDiag block
ModF STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Module Failure information from MMDiag block
Slv_Typ BOOL FALSE 0 = PROFIBUS
1 = PROFINET
DevFunc
DWORD
16#00
SIMOCODE Device Functions
RdWrEn
BOOL
TRUE
1 = Enable read / write data record
RdDataLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Input 0->1: Read record via Link or SFC
RdDataOp
BOOL
FALSE
1 = Read data from datasets
BatchEn BOOL FALSE Enable Remote Operation of Controller by Batch Rec-
ipe
BatchID
DWORD
16#00
Current Batch ID (number)
BatchName
STRING
–
Current batch name
StepNo
DWORD
16#00
Batch step number
Occupied
BOOL
FALSE
1 = Occupied by batch control
PZDIn01
WORD
16#00
Process value DP 0.0-1.7
