Siemens SIMOCODE pro PCS 7 User Manual

Description of the blocks
4.4 Block for MMMeas measured value function
SIMOCODE pro PCS 7 Library V9.0
156 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
4.4.4 Measured values
The MMMeas block reads measured values via data record DS94.
Table 4- 61 DS94
No. Data record
number
Read access/write
access
Number of
bytes
Description
1 DS94 R 64 Read measured values
The values are read from the SIMOCODE pro device with the "RDREC" function. This
information is written to the output parameters.
Measured values for SIMOCODE pro devices
The measured values depend on the type of the basic unit, and on the expansion modules
used (UM, AM, TM, EM, MM).
Note
Unsupported values are read and displayed as zero.
Table 4- 62 Measured values for SIMOCODE pro PROFIBUS devices
Function SIMOCODE
pro C E01
SIMOCODE
pro V from
E01/E02
SIMOCODE
pro S
Parameter
Thermal memory
available on current / voltage measuring modules
UM
ThmMotMod
Phase unbalance PhaUnbal
Maximum current I_max ImMax
Current I_L1 CurrL1
Current I_L2 CurrL2
Current I_L3 CurrL3
Last trip current TripCurr
Time to trip TripTime
Cooling-down period MotColTm
UM – active power ActPower
UM – apparent power AppPower
UM – Cos-Phi – available on
current /
voltage
measuring
modules UM
– MotCosPhi
UM – voltage U_L1 – – MotVol1
UM – voltage U_L2 – – MotVol2
UM – voltage U_L3 – – MotVol3
