Siemens SIMOCODE pro PCS 7 User Manual

Parameter
A.4 Block parameter MMMeas
SIMOCODE pro PCS 7 Library V9.0
252 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
See also
Description of MMOprtn (Page 100)
A.4
Block parameter MMMeas
Input parameters
Table A- 13 MMMeas input parameter
Parameter
Data format
Default setting
Meaning
Mode
DWORD
16#8000FFFF
OMODE information from MOD_SWT block
DAddr INT 0 Diagnostic address of SIMOCODE module
LAddr
INT
0
Logical address of the SIMOCODE module
RackF STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Rack Failure information from MMDiag block
ModF STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Module Failure information from MMDiag block
Slv_Typ BOOL FALSE 0 = PROFIBUS
1 = PROFINET
BasicTyp
INT
1
Basic type 1, 2 or 3
DevFunc
DWORD
16#00
SIMOCODE Device Functions
ModlAvl
WORD
16#00
Temperature and analog modules / sensors available
RdEn
BOOL
TRUE
1 = Enable read data record
RdDataLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Input 0->1: Read record via Link or SFC
RdDataOp
BOOL
FALSE
1 = Read data from datasets
BatchEn BOOL FALSE 1 = Enable status
Enabling the block for operation via SIMATIC BATCH
BatchID
DWORD
16#00
Current batch number
BatchName
STRING
–
Current batch name
StepNo
DWORD
16#00
Batch step number
Occupied
BOOL
FALSE
1 = Occupied by batch control
PZDIn01
WORD
16#00
Process value DP 0.0-1.7
PZDIn45
WORD
16#00
Process value DP 4.0-5.7 basic type 1
PZDIn67
WORD
16#00
Process value DP 6.0-7.7 basic type 1
PZDIn89 WORD 16#00 Process value DP 8.0-9.7 basic type 1
PZDIn10
WORD
16#00
Process value DP 10.0-11.7 basic type 3
PZDIn12
WORD
16#00
Process value DP 12.0-13.7 basic type 3
