Siemens SIMOCODE pro PCS 7

Parameter
A.3 Block parameter MMOprtn
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
251
Parameter
Data format
Default setting
Meaning
FbkOut1 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Feedback fast forward / Reverse on / Positioner
closed
FbkOut2 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Feedback motor off
FbkOut3 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Feedback Forward on / Motor on / Positioner
open
FbkOut4 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Feedback fast reverse / Positioner opening
FbkOut5 STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Feedback Reverse on / Positioner closing
OosAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Out of service is active
MotCurr STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Actual motor current (%)
MotCurrE STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Actual motor current in Amps
CtrlFunc
BYTE
16#00
Control function
OS_PermOut
DWORD
16#FFFFFFFF
Operator Permission: Output for OS
OS_PermLog
DWORD
16#FFFFFFFF
Operator Permission: Output for OS
OpSt_Out
DWORD
16#00000000
Enabled operator stations
ST_Worst
BYTE
16#80
Worst Signal Status
Status1
DWORD
16#00000000
Status word 1
ErrorNum
INT
-1
Error number
MsgErr1
BOOL
FALSE
1 = Messaging Error Occurs
MsgStat1
WORD
16#00
ALARM_8P: Status Output
MsgAckn1
WORD
16#00
ALARM_8P: ACK_STATE Output
MsgErr2
BOOL
FALSE
1 = Messaging Error Occurs
MsgStat2
WORD
16#00
ALARM_8P: Status Output
MsgAckn2
WORD
16#00
ALARM_8P: ACK_STATE Output
ReserveOut
WORD
16#00
Reserved
