A.4 Block parameter MMMeas
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
253
Parameter
Data format
Default setting
Meaning
PZDIn14
WORD
16#00
Process value DP 14.0-15.7 basic type 3
PZDIn16 WORD 16#00 Process value DP 16.0-17.7 basic type 3
PZDIn18
WORD
16#00
Process value DP 18.0-19.7 basic type 3
ModeIn45 INT 0
Mode
of analog input PZDIn45
ModeIn67
INT
0
Mode of analog input PZDIn67
ModeIn89
INT
0
Mode of analog input PZDIn89
ModeIn10
INT
0
Mode of analog input PZDIn10
ModeIn12
INT
0
Mode of analog input PZDIn12
ModeIn14
INT
0
Mode of analog input PZDIn14
ModeIn16
INT
0
Mode of analog input PZDIn16
ModeIn18
INT
0
Mode of analog input PZDIn18
AM1OutRg STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Analog Output Module 1 Range for Calculation
AM1InRg STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Analog Input Module 1 Range for Calculation
AM2OutRg STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Analog Output Module 2 Range for Calculation
AM2InRg STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Analog Input Module 2 Range for Calculation
AMOutIn STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Operator Input for output analog Module 1
AMOutLi STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Linked Input for output analog Module 1
AM2OutIn STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Input operator for analog module 2 – output
AM2OutLi STRUCT
• Value: REAL
• ST: BYTE
–
• 0.0
• 16#80
Linked Input for output analog Module 2
LiOp STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
0 = Operator
1 = Link
OnOp BOOL FALSE 1 = ON mode:
ON mode by operator
