Siemens SIMOCODE pro PCS 7 User Manual

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
105
CtrlFunc parameter
The CtrlFunc parameter contains the value of the configured control function of SIMOCODE,
e.g. direct starter.
Table 4- 14 Assignment
Bit
Control function
0
Overload relay
1 Direct starter
2
Reversing starter
3
Linked device (MCCB)
4
Star-delta starter
5
Star-delta reversing starter
6
Dahlander
7
Dahlander reversing starter
8
Pole-changing starter
9
Pole-changing reversing starter
10
Valve
11
Positioner 1
12
Positioner 2
13
Positioner 3
14
Positioner 4
15
Positioner 5
16
Soft starter
17
Soft reversing starter
