Siemens SIMOCODE pro PCS 7

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
128 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Soft starter with reversing contactor control function
Table 4- 37 Soft starter with reversing contactor – Process image inputs and outputs
Bit
MMOprtn – output pa-
rameters
PII – Meaning
PIO – Meaning
Bit 0.0
FbkOut1
Status – ON <
PLC/PCS [DP] → ON <
Bit 0.1 FbkOut2 Status – OFF PLC/PCS [DP] → OFF
Bit 0.2
FbkOut3
Status – ON >
PLC/PCS [DP] → ON >
Bit 0.3 PreWrnOvl Event – Prewarning overload
(I>115 %)
Test 1 – Input
Bit 0.4
IntlAct
Status – Interlock time active
Emergency start – Input
Bit 0.5
LocalAct
Status – Remote mode
Mode selector S2
Bit 0.6
GenFlt
Status – General fault
Reset 1 – Input
Bit 0.7
GenWarn
Status – General warning
–
Bit 1.0
–
–
–
Bit 1.1
–
–
–
Bit 1.2
–
–
–
Bit 1.3
–
–
–
Bit 1.4
–
–
–
Bit 1.5
–
–
–
Bit 1.6
–
–
–
Bit 1.7
–
–
–
Byte 2
PZDIn23
Maximum current I_max
–
Byte 3
PZDIn23
Maximum current I_max
–
Byte 4
–
–
–
Byte 5
–
–
–
Byte 6
–
–
–
Byte 7
–
–
–
Byte 8 – – –
Byte 9
–
–
–
