Siemens SIMOCODE pro PCS 7

Description of the blocks
4.3 MMOprtn block
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
141
Bit assignment Diag_Sts
Table 4- 53 Bit assignment Diag_Sts
Auxiliary variables
Diag_Sts
bit
Event
Diag_Sts
0
Group fault
1 General warning
2
Device
3
Bus
4
PLC/PCS
5
Motor current flowing
6
ON <<
7
ON <
8
OFF
9
ON >
10
ON >>
11
Start active
12
Interlocking time active
13
Change-over pause active
14
Runs in open direction
15
Runs in close direction
16
Feedback close
17
Feedback open
18
Torque close
19
Torque open
20
Cold starting (TPF) test position feedback
21
Operational Protection Off (OPO)
22 Remote mode
23
Emergency start executed
24 Cooling down period active
25
Pause time active
26
Device check active
27
Phase sequence 1-2-3
28
Phase sequence 3-2-1
29
DM-F enabling circuit
