4.7 MMRevDhl motor block
SIMOCODE pro PCS 7 Library V9.0
214 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Message block MsgEvId1
Table 4- 99 Output messages
Message block
Message
No.
Block parameters
Message text
Message
class *
MsgEvId1
1
Message-1
$$BlockComment$$Monitoring Error or
Starter tripped
S
2
Message-2
$$BlockComment$$Motor protection trig-
gered
S
3
CSF
$$BlockComment$$Control System Fault
S
4
ExtMsg1 **
$$BlockComment$$External message 1
S
5
ExtMsg2 **
$$BlockComment$$External message 2
S
6
ExtMsg3 **
$$BlockComment$$External message 3
S
7
–
–
–
8
–
–
–
* S = AS, OS process control fault
** User-definable message
Table 4- 100 Structure of the auxiliary values ALARM_8P
Message No.
Auxiliary
value
Block parameters
Meaning
1
1
SarBatchName
Name of batch
2
2
SdwStepNoLoc
Step number
3
3
SdwBatchId
ID of the batch
4
4
ExtVa104
External value 4, user-definable
5
5
ExtVa105
External value 5, user-definable
6
6
ExtVa106
External value 6, user-definable
7
7
ExtVa107
External value 7, user-definable
8
8
ExtVa108
External value 8, user-definable
9
9
ExtVa109
Reserved
10
10
ExtVa110
Reserved
The MsgStat1, MsgAckn1 and MsgErr1 parameters transfer the following information:
● Message status
● Message error
● Message acknowledgment status
