Description of the blocks
4.7 MMRevDhl motor block
SIMOCODE pro PCS 7 Library V9.0
220 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Status3
Table 4- 106 Status3 – MMRevDhl
Status3
bit
Description
0...7
Not used
8 Indication of motor protection (Trip.Status ≠ 16#FF)
9
1 = Input parameter FbkFwd is connected
10
1 = Input parameter FbkRev is connected
11
1 = Input parameter FbkFFwd is connected
12
1 = Input parameter FbkFRev is connected
13
SimLiOp.Value
14
1 = Enable rapid stop
15
Rapid stop command
16
Start motor forward command
17
Start motor in reverse command
18
Start motor fast forward command
19
Start motor in fast reverse command
20
GrpErr.Value
21
RdyToStart.Value
22
Auxiliary value 1 visible
23
Auxiliary value 2 visible
24 External error generated by FaultExt or external control system fault from CSF with
set Feature bit 18 Activating error state for external process control error CSF
25
Hidden bypass signal in Permit
26
Hidden bypass signal in Interlock
27
Hidden bypass signal in Protect
28
Feature2 bit 2: Separate bypass signal
29
MonDynStopErr.Value
30
Feature2 bit 16: Separate interlock for each direction or position
31
Separate monitoring of shutdown of the motor (Feature bit 13)
