Siemens SIMOCODE pro PCS 7 User Manual

Parameter
A.2 Structure of UDTs for MMDiag
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
241
Element
Data format
Meaning
EXTGNDFLT
BOOL
External earth fault
THRMOVL BOOL Thermistor trip level
THRMSHRT
BOOL
Thermistor short circuit
THRMOPN BOOL Thermistor open circuit
TMPWRNHI
BOOL
TM1 level T >
TMSNRERR
BOOL
TM1 sensor fault
TMOUTRNG
BOOL
TM1 out of range
CURWRNHI
BOOL
Level I >
CURWRNLO
BOOL
Level I <
PWRWRNHI
BOOL
Level P >
PWRWRNLO
BOOL
Level P <
COSPHIWRNLO
BOOL
Level Cos-Phi <
VOLWRNLO
BOOL
Level U <
WRN4TO20HI
BOOL
AM1 level 0/4-20mA >
WRN4TO20LO
BOOL
AM1 level 0/4-20mA <
STALROT
BOOL
Stalled rotor
NOSTRTPOS
BOOL
No start possible
NOSTRTHI
BOOL
Number of starts >
ONESTRT
BOOL
Just one start possible
MOTOPHHI
BOOL
Motor operating hours >
MOTSTPTMHI
BOOL
Motor stop time >
EXTFAULT1
BOOL
External fault 1
EXTFAULT2 BOOL External fault 2
EXTFAULT3
BOOL
External fault 3
EXTFAULT4 BOOL External fault 4
EXTFAULT5
BOOL
External fault 5
EXTFAULT6
BOOL
External fault 6
AMOPNCKT
BOOL
AM1 open circuit
DMFSAFETRP
BOOL
DM-F safety-oriented tripping
DMFTSTREQ
BOOL
DM-F monitoring interval for mandatory testing - test required
DMFLFBKCKT
BOOL
DM-F feedback circuit
DMFLSIM
BOOL
DM-FL simultaneity
EMOPNCKT
BOOL
EM open circuit
EMSHRTCKT
BOOL
EM short circuit
