Parameter
A.2 Structure of UDTs for MMDiag
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
243
Element
Data format
Meaning
TMABVRAN
BOOL
TM1 out of range
CURTRPHI BOOL Level I >
CURTRPLO
BOOL
Level I <
PWRTRPHI BOOL Level P >
PWRTRPLO
BOOL
Level P <
COSPHITRPLO
BOOL
Level Cos-Phi <
VOLTRPLO
BOOL
Level U <
TRP4TO20HI
BOOL
AM1 Level 0/4-20mA >
TRP4TO20LO
BOOL
AM1 Level 0/4-20mA <
STLRTR
BOOL
Stalled rotor
NOSTRTHI
BOOL
Number of Starts >
EXTERR1
BOOL
External fault 1
EXTERR2
BOOL
External fault 2
EXTERR3
BOOL
External fault 3
EXTERR4
BOOL
External fault 4
EXTERR5
BOOL
External fault 5
EXTERR6
BOOL
External fault 6
AMOPNCKT
BOOL
AM1 open circuit
TSTTRP
BOOL
Test shutdown
DMFSAFETRP
BOOL
DM-F safety-oriented tripping
DMFWIR
BOOL
DM-F wiring
DMFLCRSCKT
BOOL
DM-FL cross circuit
EMOPNCKT BOOL EM open circuit
EMSHRTCKT
BOOL
EM short circuit
Table A- 10 SMCTRP – trip diagnostics information for SIMOCODE pro PROFINET devices
Element
Data format
Meaning
TM2TRPHI BOOL TM2 level T >
TM2SNSERR
BOOL
TM2 sensor fault
TM2ABVRAN
BOOL
TM2 out of range
AM24TO20HI
BOOL
AM2 level 0/4-20mA >
AM24TO20LO
BOOL
AM2 level 0/4-20mA <
AM2OPNCKT
BOOL
AM2 open circuit
