Siemens SIMOCODE pro PCS 7 User Manual

Parameter
A.3 Block parameter MMOprtn
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
245
Parameter
Data format
Default setting
Meaning
PZDIn01
WORD
16#00
Value of process image input DP 0.0–1.7
PZDIn23 WORD 16#00 Value of process image input DP 2.0–3.7
PZDOut01
WORD
16#00
Process image output
EmrgStMan BOOL FALSE 1 = Emergency Start Active, Manual Mode Com-
mand
CstMan
BOOL
FALSE
1 = Test Active, Manual Mode Command
CstAut STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Self Test Active, Auto Mode Command
EmrgStAut STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Emergency Start Active, Auto Mode Command
TrpRstLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Trip reset active, by Link or SFC
TrpRstOp
BOOL
FALSE
1 = Trip Reset Active, Manual Mode Command
RdyToRst STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Ready to trip reset active
OosOp
BOOL
FALSE
1 = Out of service, via OS operator
OosLi STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Oos Mode: Oos Mode by Field Signal
SampleTime
REAL
0,1
Sampling Time [s]
MsgLock STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Inhibit process message
RunUpCyc INT 3 Number of cycles for which all messages are sup-
pressed
Curr_OpScale STRUCT
• HIGH: REAL
• LOW: REAL
–
• 1020.0
• 0.0
Bar Display Limits for OS
MsgEvId1
DWORD
16#FF
Message Event ID 1 (assigned automatically)
MsgEvId2
DWORD
16#FF
Message Event ID 2 (assigned automatically)
CSF STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Control System Fault Message - External Error
Curr_TH
INT
0
Trip level high 0…1020%
Curr_WH INT 0 Warning level high 0…1020%
Curr_TL
INT
0
Trip level low 0…1020%
