Parameter
A.6 Block parameter MMLog
SIMOCODE pro PCS 7 Library V9.0
270 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
Feature STRUCT
• Bit 0: BOOL
• ...
• Bit 31:
BOOL
–
• 0
• 0
• 0
Status of various features
ReserveIn WORD 16#00 Reserved
Output parameters
Table A- 20 Output parameter MMLog
Parameter
Data format
Default setting
Meaning
RackF_Act STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Rack Failure
ModF_Act STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Module Failure
RdErr STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Error read record
RdErrStat
WORD
16#00
Status of read record error
StaTmst
BYTE
0
Status of time stamp functionality
TmstmpAct STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Time stamp functionality active
Sync_Ok
BOOL
FALSE
1 = Synchronization ok
OflwBuf
BOOL
FALSE
1 = Buffer overflow
RdAct
BOOL
TRUE
1 = Enable read/write record
LocalAct STRUCT
• Value:
BOOL
• ST: BYTE
–
• 1
• 16#80
1 = Motor in Local Operation Mode: Local Mode Indicator
OnAct STRUCT
• Value:
BOOL
• ST: BYTE
–
• 1
• 16#80
On Mode is active
