A.6 Block parameter MMLog
SIMOCODE pro PCS 7 Library V9.0
272 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
SigMsg6 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 6
SigMsg7 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 7
SigMsg8 STRUCT
• Value:
BOOL
• ST: BYTE
–
• 0
• 16#80
Signal Message 8
MsgErr1 BOOL FALSE 1 = Messaging Error Occurs ALARM_8P1
MsgErr2
BOOL
FALSE
1 = Messaging Error Occurs ALARM_8P2
MsgStat1
WORD
16#00
ALARM_8P1: Status Output
MsgStat2
WORD
16#00
ALARM_8P2: Status Output
MsgAckn1
WORD
16#00
ALARM_8P1: ACK_STATE Output
MsgAckn2
WORD
16#00
ALARM_8P2: ACK_STATE Output
ErrorNum
INT
1
Error Number
ReserveOut
WORD
16#00
Reserved
Structure of OMODE
Table A- 21 Structure of OMODE – MMLog
Bytes
Value
Meaning
Byte 3 16#80:
16#40:
16#20:
Valid data
Invalid data
Redundancy error
Irrelevant
Byte 2
16#01:
Warm restart (OB100)
–
Byte 1; 0
16#0000
–
Irrelevant
