Parameter
A.7 Block parameter MMRevDhl
SIMOCODE pro PCS 7 Library V9.0
282 Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Parameter
Data format
Default setting
Meaning
RunFFwd STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor running with Fast Forward
RunFwd STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor running forward
Stop STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor STOP
RunRev STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor running reverse
RunFRev STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor running with Fast Reverse
Starting STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor starting
Stopping STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor stopping
OS_PermOut
DWORD
16#FFFFFFFF
Operator Permission: Output for OS
OS_PermLog
DWORD
16#FFFFFFFF
Operator Permission: Output for OS
OpSt_Out
DWORD
16#00000000
Enabled operator stations
Status1
DWORD
16#00000000
Status1 Word
Status2
DWORD
16#00000000
Status2 Word
Status3
DWORD
16#00000000
Status3 Word
Status4
DWORD
16#00000000
Status4 Word
ST_Worst
BYTE
16#80
Worst Signal Status
AutoST
BYTE
16#80
Worst Signal Status of the Automatic Commands
ErrorNum
INT
-1
Error Number
MsgErr1
BOOL
FALSE
1 = Messaging Error Occurs
MsgStat1
WORD
16#00
Message status 1
MsgAckn1
WORD
16#00
Message acknowledgement status 1
MsgErr2
BOOL
FALSE
1 = Messaging Error Occurs
MsgStat2
WORD
16#00
Message status 2
MsgAckn2 WORD 16#00 Message acknowledgement status 2
ReserveOut
WORD
16#00
Reserved
