Siemens SIMOCODE pro PCS 7 User Manual

Parameter
A.7 Block parameter MMRevDhl
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
281
Parameter
Data format
Default setting
Meaning
P_Stop STRUCT
• Value: BOOL
• ST: BYTE
–
• 1
• 16#80
Pulsive Control Output to Stop
P_Rev STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Pulsive Control Output to Start Motor Reverse
P_FRev STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Pulsive Control Output to Start Motor Reverse
P_Rst STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Reset Impulse
LocalAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Motor in Local Operation Mode: Local Mode Indicator
AutAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
1 = Auto: Automatic Mode Indicator
ManAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 1
• 16#80
Manual value is active
OosAct STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Out of service is active
FbkFFwdOut STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Feedback of Control Fast Forward
0 = Stop
1 = Fast Forward
FbkFwdOut STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Feedback of Control Forward
0 = Stop
1 = Run
FbkRevOut STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Feedback of Control Reverse
0 = Stop
1 = Run
FbkFRevOut STRUCT
• Value: BOOL
• ST: BYTE
–
• 0
• 16#80
Feedback of Control Fast Reverse
0 = Stop
1 = Fast Reverse
