Delay time
The SBR function only starts after an adjustable time. To begin with, the inverter monitors the
speed setpoint that applied when SS1 was selected.
Braking
The inverter brakes the motor with the OFF3 ramp-down time.
Shutdown speed
The inverter safely switches off the motor torque using the STO function if the speed has
reached the shutdown speed.
Parameter Description
p9501.00 Enable safety functions
1 signal: Enable extended functions.
0 signal: Disable extended functions.
p9506 Function specification: (Factory setting: 1)
1: With braking ramp monitoring
3: With acceleration monitoring
p9546 SSM speed limit (factory setting: 20 rpm)
Only relevant to the SS1 function if p9560 = 0.
p9560 Pulse cancellation shutdown speed (factory setting: 10 rpm)
Shutdown speed
p9581 Brake ramp reference value (factory setting: 1500 rpm)
Reference speed for SBR
p9582 Brake ramp delay time (factory setting: 250 ms)
p9583 Brake ramp monitoring time (factory setting: 10 s)
r9722.1 Status signals
1 signal: SS1 active
r9714 Speed diagnostics [rpm]
[0] Load-side speed actual value
Electrical speed of the motor. For induction motors, the mechanical speed is ob‐
tained from the electrical speed and slip.
[1] Actual SAM/SBR speed limit
r9723.16 1 signal: SAM/SBR active
p1135 OFF3 ramp-down time
p1226 Standstill detection, speed threshold (Fac‐
tory setting: 20 rpm)
The inverter switches off the motor torque
if the speed either fulfills the condition for
standstill detection or the shutdown
speed p9569 has been reached.
p1227 Standstill detection monitoring time (Value
depends on the power unit)
Commissioning
5.12 Setting extended functions
Safety Integrated - SINAMICS G110M, G120, G120C, G120D and SIMATIC ET 200pro FC-2
Function Manual, 01/2017, FW V4.7 SP6, A5E34261271B AD 179
