Name Number Value
SI SLS input terminal p10026 <p10026_v>
SI SDI positive input terminal p10030 <p10030_v>
SI SDI negative input terminal p10031 <p10031_v>
SI F-DI monitoring status r10049 <r10049_v>
SI PROFIsafe transfer F-DI p10050 <p10050_v>
Table A-12 Fail-safe digital output in the SINAMICS G120D with CU240/250D‑2 DP/PN F and in the SINAMICS G120 with
CU250S‑2
Name Number Value
SI wait time for test stop at DO p10001 <p10001_v>
SI forced checking procedure timer p10003 <p10003_v>
SI forced checking procedure F-DO signal source p10007 <p10007_v>
SI safe state signal selection p10039 < p10039_v>
SI F-DO 0 signal sources p10042[0] <p10042[0]_v>
p10042[1] <p10042[1]_v>
p10042[2] <p10042[2]_v>
p10042[3] <p10042[3]_v>
p10042[4] <p10042[4]_v>
p10042[5] <p10042[5]_v>
SI F-DO feedback signal input activation p10046 <p10046_v>
SI F-DO test stop mode p10047 <p10047_v>
Table A-13 Safety logbook
Name Number Value
SI change control checksum r9781[0] <r9781[0]_v>
SI change control checksum r9781[1] <r9781[1]_v>
SI change control time stamp r9782[0] <r9782[0]_v>
SI change control time stamp r9782[1] <r9782[1]_v>
Appendix
A.3 Documentation for acceptance
Safety Integrated - SINAMICS G110M, G120, G120C, G120D and SIMATIC ET 200pro FC-2
420 Function Manual, 01/2017, FW V4.7 SP6, A5E34261271B AD

Siemens SINAMICS G120C Specifications

General

Communication Interfaces	PROFINET, PROFIBUS, USS, Modbus RTU
Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Storage Temperature	-40°C to +70°C
Power Range	0.55 kW to 132 kW
Voltage Range	380 V to 480 V
Output Voltage	0 V to Supply Voltage
Frequency Range	0 Hz to rated output frequency
Control Modes	Vector control with encoder
Protection	Overload, overvoltage, undervoltage, short circuit, ground fault
Relative Humidity	5% to 95%, non-condensing
Altitude	Up to 2000 m without derating
