SINUMERIK 802D sl Operating and Service Training Manual Page 4
C83
C83
Section 2
Working Plane Selection
This is how the axis are assigned from MILLING to TURNING under
ISO STANDARDS.
Make a note of axis assigned to Length1 & Length2 for Turning.
A turning machine has no Y
axis, the defa
ult plane is ZX
(G18). In the c
ase of turning
tools the offset L1 is a
pplied
to X
With G19 on a turning
machi
ne, there is no Y
axis, in the ca
se of a
turning tool L
2 is then
assign
ed to the Z axis.
With G17 on a
turning m
achine,
there is n
o Y
axis. Comp
ensa-
tion L3 is there-
