Siemens SINUMERIK 840D sl Function Manual

Detailed description
2.3 Starting up hardware configuration of PLC CPUs
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
19
NCU MLFB
Comparable
SIMATIC CPU MLFB
included
Selection from STEP7 hardware
catalog
SINUMERIK 840D/DE NCU
572.2 without system
software
6FC5 357-0BB24-0AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D NCU 572
(export version) with
digitizing
6FC5 357-0BY24-0AE0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
SINUMERIK 840D NCU
572.2 (export version) with
digitizing and PROFIBUS DP
6FC5 357-0BY24-1AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D NCU 573 6FC5 357-0BA30-0AE0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
SINUMERIK 840DE NCU
573 (export version)
6FC5 357-0BY30-0AE0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
SINUMERIK 840D NCU 573
with digitizing
6FC5 357-0BA31-0AE0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
SINUMERIK 840D NCU 573
(export version) with
digitizing
6FC5 357-0BY31-0AE0 6ES7 314-1AE01-0AB0 810D/840D with PLC314
SINUMERIK 840D NCU 573
with PROFIBUS DP
6FC5 357-0BA32-0AE1 6ES7 315-2AF00-0AB0 840D with PLC3152AF00
SINUMERIK 840D NCU 573
(export version) with
PROFIBUS DP
6FC5 357-0BY32-0AE1 6ES7 315-2AF00-0AB0 840D with PLC3152AF00
SINUMERIK 840D NCU 573
with PROFIBUS DP
6FC5 357-0BA33-0AE0 6ES7 315-2AF00-0AB0 840D with PLC3152AF00
SINUMERIK 840D NCU 573
(export version) with
PROFIBUS DP
6FC5 357-0BY33-0AE0 6ES7 315-2AF00-0AB0 840D with PLC3152AF00
SINUMERIK 840D NCU
573.2 (Pentium Pro) up to 12
axes with PROFIBUS DP
6FC5 357-0BA32-1AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D NCU
573.2 (Pentium Pro) up to 31
axes with PROFIBUS DP
6FC5 357-0BA33-1AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D/DE NCU
573.2 without system
software
6FC5 357-0BB33-0AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D/DE NCU
573.2 Pentium II without
system software
6FC5 357-0BB33-0AE1 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D NCU
573.2 (Pentium Pro) for
digitizing with PROFIBUS DP
6FC5 357-0BA31-1AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01
SINUMERIK 840D/DE NCU
573.2 without system
software
6FC5 357-0BB31-0AE0 6ES7 315-2AF01-0AB0 810D/840D with PLC3152AF01

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
