Siemens SINUMERIK 840D sl Function Manual

Basic logic functions: Spindles (S1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
97
Data lists
5
5.1 Machine data
5.1.1 NC-specific machine data
Number Identifier: $MN_ Description
10192 GEAR_CHANGE_WAIT_TIME Wait time for acknowledgment of a gear stage change
during reorganization
10714 M_NO_FCT_EOP M function for spindle active after RESET
12060 OVR_SPIND_IS_GRAY_CODE Spindle override with Gray coding
12070 OVR_FACTOR_SPIND_SPEED Evaluation of spindle speed override switch
12080 OVR_REFERENCE_IS_PROG_FEED Override reference velocity
5.1.2 Channelspecific machine data
Number Identifier: $MC_ Description
20090 SPIND_DEF_MASTER_SPIND Initial setting for master spindle on channel
20092 SPIND_ASSIGN_TAB_ENABLE Enabling/disabling of spindle converter
20850 SPOS_TO_VDI Output of auxiliary function "M19" to the
VDI interface
22400 S_VALUES_ACTIVE_AFTER_RESET S function active after RESET

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
