Siemens SINUMERIK 840D sl Function Manual

Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
180 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Call example
FUNCTION FC 99: VOID
TITLE =
VERSION : 0.0
BEGIN
NETWORK
TITLE = NETWORK
CALL FB 29, DB 80 (
Func
:= 1,
Signal_1 :=M 100.0,
Signal_2 :=M 100.1,
Signal_3 :=M 100.2,
Signal_4 :=M 100.3,
Signal_5 :=M 10.4,
Signal_6 :=M 100.5,
Signal_7 :=M 100.6,
Signal_8 :=M 100.7,
NewCycle := TRUE,
Var1 := MB 100,
BufDB := 81,
ClearBuf :=M 50.0);
END_FUNCTION
2.12.11 FC 2: GP_HP Basic program, cyclic section
Description of Functions
The complete processing of the NCKPLC interface is carried out in cyclic mode. In order to
minimize the execution time of the basic program, only the control/status signals are
transmitted cyclically; transfer of the auxiliary functions and G functions only takes place
when requested by the NCK.
Declaration
FUNCTION FC 2: VOID
//No parameters

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
