Siemens SINUMERIK 840D sl Function Manual

Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
134 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.12.4.3 Tool management services
Overview of PI services
Available PI services of the function tool management.
PI service Function FM-NC 840D
CRCEDN Create new cutting edge *
CREACE Create cutting edge * *
CREATO Generate tool * *
SETUFR Activate user frames * *
DELECE Delete a cutting edge *
DELETO Delete tool * *
MMCSEM Semaphores for various PI services *
TMCRTO Create tool *
TMFDPL Empty location search for loading *
TMFPBP Empty location search *
TMMVTL Prepare magazine location for loading, unload tool *
TMPOSM Position magazine location or tool *
TMPCIT Set increment value for workpiece counter *
TMRASS Reset active status *
TRESMO Reset monitoring values *
TSEARC Complex search using search screen forms *
x: PI service is available
