Detailed Description
2.1 Spindle modes
Basic logic functions: Spindles (S1)
32 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.1.6 Default mode setting
Machine data
The default setting of the spindle mode allows configuration of the basic spindle setting
following Power On, NC-START and RESET using machine data:
MD35020 $MA_SPIND_DEFAULT_MODE
and
MD35030 $MA_SPIND_DEFAULT_ACT_MASK
.
0'63,1'B'()$8/7B02'(
0'63,1'B'()$8/7B$&7B0$6.
5(6(7
3RZHU21
1&67$57
6SHHGPRGHZRSRVFRQWU
6SHHGPRGHZLWKSRVFRQWU
3RVLWLRQLQJPRGH
$[LVPRGH
6WDQGDUGVHWWLQJ
Figure 2-5 Programmable defaults for spindle operating mode
