Siemens SINUMERIK 840D sl Function Manual

Detailed Description
2.1 Spindle modes
Basic logic functions: Spindles (S1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
31
Table 2-2 Switch back to spindle mode
C=...
M71
→ Output to PLC
Closed-loop controller enable off (by PLC)
Switch actuator (by PLC)
Switched to spindle parameter set (1-5) internally in the NC,
controller enable on (by PLC)
M3/4/5
or
SPOS=...
NC travels with spindle parameter set
Change to spindle mode
The interpolation parameter (set 1 ... 5) is selected according to the currently valid gear step.
The feedforward control function is always activated, except for tapping with compensating
chuck.
Machine data:
MD32620 $MA_FFW_MODE (feedforward control type)
must always be not equal to 0.
Feedforward control should always be operated with the value 100% to avoid alarms being
output during positioning.






$[LVPRGH 6SLQGOHPRGH
'HSHQGLQJRQJHDUVWHS
3DUDPHWHUVHW
9DOLG
9DOLG
9DOLG
9DOLG
9DOLG
9DOLG
Figure 2-4 Validity of parameter sets for axis and spindle modes

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
